NodeBox

Glacier

Glacier draws a grid of interconnecting hexagonal elements with a recursive algorithm. The grid fades out after a certain amount of tiles. The algorithm contains a bug in the way hexes are spaced, but this actually creates a nice visual effect: the glaciers start drifting apart the further they are from the core. A global warming bug!

Source code:

size(600, 600)

hexwork = {}

class Hex:

  def __init__(self, x, y, w, spacing=0):

    #Creates a new hexagonal at position x, y
    #with the given width w, and optional spacing.
    #Adds itself to the hexwork list.

    self.x = x
    self.y = y
    self.w = w
    self.spacing = spacing

    self.sides = []
    for i in range(6):
      self.sides.append(None)
    global hexwork
    hexwork[(self.x,self.y)] = self
    self.index = len(hexwork)

  def draw(self, tag=False, visit=None):

    #Draws this hexagonal on screen.
    #Optionally, tags the hexagonal with its index
    #in the hexwork list.

    #Additionally, you can supply a visit function
    #that accepts this self as a parameter.

    if visit != None: visit(self)

    w = self.w * 0.5
    star(self.x, self.y, 6, w, w*1.155)

    if tag:
      fontsize(w*0.25)
      f = fill()
      fill(f.r, f.g, f.b, 1)
      align(CENTER)
      text(str(self.index), self.x-self.w*0.5, self.y, self.w)
      fill(f)

  def rdraw(self, tag=False, visit=None, degrade=True, root=None):

    #Recursive draw:
    #draw all neighbours as well,
    #and their neighbours, and so on.

    if degrade == True:
      f = fill()
      fill(f.r, f.g, f.b, f.a * 0.98)

    self.draw(tag, visit)
    if root != None: line(self.x,self.y,root.x,root.y)
    for side in self.sides:
      if side != None and side != root:
        side.rdraw(tag, visit, degrade, root=self)

  def grow(self, max=6):

    #Creates neighbouring hexes for this hexagonal.
    #Creates all neighbours by default, or a given max
    #of random neighbours.

    if max < 1 or max > 6: return

    #The centerpoint offsets for neighbouring hexes.

    from random import shuffle
    center = [(0,-1),
              (-0.865,-0.5),
              (-0.865,0.5),
              (0,1),
              (0.865,0.5),
              (0.865,-0.5)]

    shuffle(center)
    center = center[:max]
    #center.sort() #doesn't do what supposed to do

    #Create neighbours only if the neighbour does
    #not exist yet: if it is not defined by this
    #hex as a neighbour already, or its position
    #occurs in the hexwork list (and thus it is
    #already defined as someone else's neighbour).

    for i in range(max):
      dx, dy = center[i]
      dx = dx * (self.w+self.spacing) + self.x
      dy = dy * (self.w+self.spacing) + self.y
      global hexwork
      if self.sides[i] == None and not hexwork.has_key((dx,dy)):
        self.sides[i] = Hex(dx, dy, self.w)
        self.sides[i].sides[(i+3)%6] = self

  def rgrow(self, max=6):

    #Recursive growth:
    #grow neighbours for this hex,
    #grow neighbours for each neighbour, and so on.

    if max > 0:
      self.grow(max)
      for side in self.sides:
        if side != None:
          side.rgrow(max-1)

def visit(hex):
  scale(random(0.98,1.01))
  rotate(0.1)

root = Hex(400,400,70, spacing=100)
root.rgrow()

nofill()
stroke(0.2,0.2,0.2)
strokewidth(0.5)
rect(0,0,WIDTH,HEIGHT)

font("Arial")
r = random(0.5,1)
fill(0,0.5,r,0.75)
stroke(0,0.5,r,0.75)
strokewidth(0.25)
root.rdraw(tag=True, visit=visit)
